High Precision Dust Concentration Detector with 0.1 - 3000 mg/m³ Measurement Range and ±15% Relative Error
High Precision Dust Concentration Detector with 0.1 - 3000 mg/m³ Measurement Range and ±15% Relative Error High Precision Dust Concentration Detector with 0.1 - 3000 mg/m³ Measurement Range and ±15% Relative Error High Precision Dust Concentration Detector with 0.1 - 3000 mg/m³ Measurement Range and ±15% Relative Error High Precision Dust Concentration Detector with 0.1 - 3000 mg/m³ Measurement Range and ±15% Relative Error High Precision Dust Concentration Detector with 0.1 - 3000 mg/m³ Measurement Range and ±15% Relative Error
Kontakt

High Precision Dust Concentration Detector with 0.1 - 3000 mg/m³ Measurement Range and ±15% Relative Error

Herkunftsort: China Markenname: topsky

Detailinformationen
Sprache: 15 Speicheraufzeichnungen: 20,000 Messungen
Außenmaterial: Kugelsicher: Aramid UD Fokus-Strecke: 0.3m ~
Linsenwinkel: 120 ° Luftfeuchtigkeit: 0-100%
Scanmodus: Phasenscanning Dauer der Analyse: ≤4 Sekunden
drahtloser Steuerabstand: 500 m Gewicht: Variiert je nach Gerätetyp, typischerweise 5–20 kg
Communicaiton für Drucker: Bluetooth Lebensdauer des Geräts: >15000 Stunden
Stromversorgung des Systems: AC220V/80W Helmschalen: ≥720 m/s
Pixel: 1080p
Hervorheben:

0.1 - 3000 mg/m³ Dust Concentration Detector

,

±15% Relative Error Dust Monitor

,

±2.5% Stability Error Dust Measurement Instrument

Produkt-Beschreibung

Dust Concentration Detector
Overview
Specification Value
Determination Principle Light scattering principle
Measurement Range 0.1 - 3000 mg/m³
Relative Error of Dust Concentration Measurement ±15%
Relative Error of Stability ±2.5%
Measurement Error ±10%
Key Features
  • Mine Safety Permit
  • Coal Safety Permit
  • Mine Explosion Prevention
  • Chemical Explosion Prevention
  • Dust Explosion Prevention
  • Multi-parameter Measurement
  • High Precision
Functions
Directly reads current dust concentration without requiring filter membrane. Includes dust data analysis software with storage capacity for over 24 hours of data.
Parameter Specification
Repeatability < 5%
Working Time Continuous operation for over 6 hours
Display Mode Liquid crystal display
Working Voltage 10V - 12V (built-in rechargeable power supply)
Charging Current Constant current 350mA (13.5V)
Dust Concentration Alarm Adjustable set point with sound and light alarm
Explosion-proof Mark ExibⅠ Mb
